Bottle-top dispensers

Calibrex^™
universal 520 bottle-top dispenser

Calibrex^TM universal 520 Bottle-top dispensers

Ordering information

Volume	Division	Cat. No.
0.25 - 2 mL	0.05 mL	520.002
1 - 5 mL	0.1 mL	520.005
1 - 10 mL	0.25 mL	520.010
Base thread fits 32 mm bottle neck diameter. Each 520 models comes along with 3 adapters (PP material) for 28, 40 and 45 mm bottle neck diameters. See bottle-neck adapters for additional sizes and materials.

Performance information

Calibrex^TMuniversal 520 Bottle-top dispensers

Performance information

Volume		Inaccuracy (E%)			Imprecision (CV%)
Range	Division	Min. vol.	Mid. vol.	Max. vol.	Min. vol.	Mid. vol.	Max. vol.
0.25 - 2 mL	0.05 mL	<± 3.0 %	<± 1.8 %	<± 0.6 %	< 0.5 %	< 0.35 %	< 0.1 %
1 - 5 mL	0.1 mL	<± 2.0%	<± 1.3 %	<± 0.6 %	< 0.5 %	< 0.35 %	< 0.1 %
1 - 10 mL	0.25 mL	<± 1.5 %	<± 1.1 %	<± 0.6 %	< 0.5 %	< 0.35 %	< 0.1 %
Performance values obtained with bidest water at constant temperature (± 0.5°C) comprised between 20 and 25°C, in accordance with ISO 8655.

Description

Designed for performance handling of liquids from a large variety of bottles and flasks, the Calibrex^TM universal 520 bottle-top dispensers combine the latest in dosing tehnology, high-tech materials and ergonomic design. They are manufactured and tested to fully comply with current safety regulations. Volumes range from 0.25 to 10 mL. Two-year warranty.

Superior chemical resistance
Long-lasting performance stability
Simple construction – no tool for disassembling
Single hand volume setting
Calibration mechanism under the cap
QR code accessing chemical compatibility chart
Autoclavable at 121°C / 250°F fully assembled

Fixed versions also available in any volume within the same ranges.

Model Selection

0.25 - 2 mL
1 - 5 mL

1 - 10 mL

Highlights

Friendly digital volume setting
Optimised working position
Air filter
In-lab calibration
Time efficient maintenance
QR coded chemical compatibility
Environment and sustainability

Videos & Documents

General presentation

Calibrex^TM Bottle-top dispensers

Catalog / Leaflet

Download

Calibrex^TM universal 520/520F Bottle-top dispensers

Operating Instruction

Download

Calibrex^TM
universal 520

Quick Guide

Download

Calibrex^TM universal 520/520F
Bottle-top dispensers

Chemical Resistance Chart

Download

Calibrex^™ universal 520 bottle-top dispenser
Bottle-top dispensers

Quick Guide

Download

Models

Accessories

Find your distributor

Find a distributor

Service & Calibration

Contact the Socorex Service & Calibration center for maintenance and calibration.

Learn more

Differentiating features	Calibrex^TMuniversal 520	Calibrex^TMorgano 525	Calibrex^TMsolutae 530
Volume range	3 models from 0.25 to 10 mL	7 models from 0.1 to 100 mL	7 models from 0.1 to 100 mL
Volume setting	Setting ring, display window	Sliding cursor along double scale	Sliding cursor along double scale
Plunger	PFA coated, universal chemical resistance	Ground glass, ideal for organic solvents	PFA coated, optimal for acids, bases and salt solutions
Stopcock	No	Available in option	Available in option
Calibration	Instant calibration with integrated key	Instant calibration with integrated key	Instant calibration with integrated key
Fixed volume	Yes	No	No
